OTT-1004 · Transformers
Square D Sorgel 5 kVA Single-Phase Transformer — 240x480V to 120/240V, NEMA 3R Rainproof
Request Quote
1 unit
| Manufacturer | Square D Company (Sorgel Transformers) |
|---|---|
| Model | 5S1F |
| Rating | 5 kVA |
| Phase | 1 Phase |
| Frequency | 60 Hz |
| High Voltage | 240 x 480 V |
| H.V. Amps | 20.8 / 10.4 A |
| Low Voltage | 120 / 240 V |
| L.V. Amps | 41.6 / 20.8 A |
| Temp Rise | 115 °C rise, 180 °C insulation system |
| Type | S |
| Class | AA |
| Weight | 110 lbs |
| Enclosure | Rainproof — NEMA Type 3R |
| Style No. | 11751-12625-005 |
| Date Code | GU |
| Instruction Manual | 7410/20-S |
| Listings | UL Listed General Purpose Transformer 31G9 |
Condition
Used. Grey enclosure with surface staining, light scuffing and dirt. Metal nameplate and UL/warning decals intact and fully legible. No rust-through or dents.
Before you orderThe SERIAL NO. box on the nameplate is blank — no serial was stamped at the factory.
How we catalog
Every specification above is transcribed from this unit's own nameplate or data label. Nothing is inferred from a model number or copied from a manufacturer catalog. Where a plate was unreadable or absent, the field is left off rather than estimated. Equipment is sold as-is; we have not powered up or performance-tested these units unless stated. Inspection is welcome and encouraged before purchase.
