OTT-2004 · Switchgear & Motor Control
ACI CK09 Reversing Contactor Pair with Adjustable Overload Relay — 24A, 600V, 3-Pole
Request Quote
1 assembly (2 contactors + 1 overload relay)
| Manufacturer | Advance Controls, Inc. (aci) |
|---|---|
| Model | CK09 |
| Configuration | 2 contactors cross-wired as a reversing pair, plus overload relay (mechanical interlock not verified from photos) |
| Amperage | 24 general purpose amps |
| Voltage | 600 VAC max |
| SCCR | 5 kA at 600 VAC |
| Poles | 3-pole (1L1 3L2 5L3 / 2T1 4T2 6T3) plus 21NC/22NC auxiliary |
| Aux Contact Rating | A600, Q300 |
| Max Fuse | 70 A Class J |
| Terminal Torque | 20 lb-in |
| Wire Size | 16-10 AWG, 75 °C copper only |
| HP 1PH | 120 V = 3/4 HP; 240 V = 2 HP |
| HP 3PH | 200 V = 3 HP; 240 V = 3 HP; 480 V = 5 HP; 575 V = 7-1/2 HP |
| Overload Range | Adjustable, dial marked 1.1 – 1.6 A |
| Listings | cULus Listed 29GZ Ind. Cont. Eq. E155477; CE |
Condition
Used, good. Housings clean with no cracks, no scorching and no contact-tip discoloration visible externally. Factory jumper wiring between the two contactors is intact. All coil and auxiliary terminals present.
Before you orderCoil voltage is not marked anywhere visible on either contactor — we will read the coil label off the unit before you order. The overload relay's own catalog number is not legible; only the 1.1–1.6 A dial scale could be read.
How we catalog
Every specification above is transcribed from this unit's own nameplate or data label. Nothing is inferred from a model number or copied from a manufacturer catalog. Where a plate was unreadable or absent, the field is left off rather than estimated. Equipment is sold as-is; we have not powered up or performance-tested these units unless stated. Inspection is welcome and encouraged before purchase.
